High Load Capacity Multi Stage Telescopic Hydraulic Cylinder Short Stroke For Concrete Pump Truck

Multi Stage Telescopic Hydraulic Cylinder Description

Our Telescopic Multi Stage Hydraulic Cylinders are designed specifically for concrete pump trucks. They employ a multi-stage sleeve structure to achieve high load support and rapid telescopic movement within an extremely short installation length, ensuring stable, efficient extension, and highly reliable operation of the pumping boom.

Our multi stage Ttelescopic hydraulic cylinders adopt a multi-section nested structure design, achieving ultra-long stroke output within an extremely short installation length. They have significant advantages such as high load-bearing capacity, compact structure, and light weight, and are widely used in concrete pump trucks, aerial work platforms, dump trucks, cranes, construction machinery and other fields to achieve efficient extension and precise positioning under heavy loads.

Hebei Runhe Machinery Co., Ltd. is a professional hydraulic manufacturer specializing in high-performance products, including hydraulic cylinders, gear pumps, gear motors, and accessories.

Our core strength lies in our highly customized services. Based on your drawings, specifications, or application needs, we offer comprehensive customization services, from design optimization and material selection to precision machining, ensuring product reliability and durability.

Multi Stage Hydraulic Cylinder Specification

Multi Stage Hydraulic Cylinder Features

1.Compact High-Load Design
Premium materials and reinforced structure deliver extreme load capacity in minimal retracted length, ideal for the root boom’s tight space and maximum bending moment.
2. Short-Stroke Multi-Stage Telescoping
Multiple short-stroke stages provide precise, progressive extension within limited space, perfectly matching the compact hinge layout of boom folding joints.
3. High-Pressure Integrated Cushioning
Built-in hydraulic cushioning at the final stage absorbs sudden stops or reversals, protecting both structure and hydraulic system from shock loads.
4. Intelligent Synchronization Control Interface
High-precision displacement sensor ports enable seamless integration with the pump truck’s control system for synchronized multi-cylinder operation and accurate boom trajectory.

Service

1.12 months warranty

2.7*24h after-sale service

3.Fast delivery

4.Customization and OEM

5.Factory visits available online and offline

Hebei Runhe Hydraulic Machinery Co., Ltd. is a subsidiary of Hanjiu Technology Group. We are a leading manufacturer specializing in hydraulic system solutions. We are also one of the most recognized suppliers of large OEM equipment manufacturers in the domestic hydraulic industry. With more than 12 years of industry experience, our professional team focuses on research and development, manufacturing and sales, and we constantly improve our product structure and functions to meet the diverse needs of our customers.

In addition to the standard series of hydraulic cylinders, we can also provide customized production services according to customer drawings. Our non-standard customization capabilities meet the special needs of customers, such as special port forms, special materials, special installation, special performance, stacked hydraulic valves, etc. Our products include hydraulic cylinder, hydraulic pump, hydraulic motor, widely used in automation equipment, agricultural machinery, lifting machinery, engineering vehicles, printing machinery, intelligent storage system, port ships and many other industries.

"Survival by quality, development by integrity" is our business philosophy, we are willing to achieve a win-win situation with friends all over the world!
