Name: P391 500x500mm rental LED Screen Stage Backdrop LED Panel Outdoor Rental Event LED Display Wall
Brand: CONWIN
Price: 1 USD

Home > Other Electronic Components >

P3.91 500x500mm rental LED Screen Stage Backdrop LED Panel Outdoor Rental Event LED Display Wall

Categories	Indoor Rental LED Display
Brand Name:	CONWIN
Model Number:	X2
Certification:	CE,ROHS
Place of Origin:	China
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	2000sqm/month
Delivery Time:	5-8 working days
Packaging Details:	wooden box or carton
Panel Material:	Die-casting Aluminium
Application:	conference, hotel, shopping mall
Led Spec:	SMD3in1
Servicing:	Front/rear
Port:	Shenzhen
Contrast Ratio:	2000:1
Screen Dimension:	500x500mm
Display Type:	P2LED display screen
Led Chip:	Nation star,NationstarSMD2020
Panel Size:	500x500mmx57mm
Size Of Panel:	500mm x1000mm
Max Hanging:	20/10
Scanning Mode:	13S
Weight:	7kgs

Contact Now

Add to Cart

Company Info.

Conwin Optoelectronic Co., Ltd.

Verified Supplier

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Description

Specification

Pixel pitch	1.953mm	2.604mm	2.976mm	3.91mm	4.81mm
Pixels per cabinet (HxV)	256×256	192×192	168×168	128×128	104×104
(500*500mm)
Pixels per cabinet (HxV)	256×512	192×384	168×336	128×256	104×208
(500*1000mm)
LED lifetime	100,000h
Brightness	Indoor:600-800 nits, Outdoor:4500-5000 nits
Module size	250*250mm
Module resolution	128*128dots	96*96dots	84*84dots	64*64dots	52*52dots
Refresh rate	3840-7,680Hz
Hor. viewing angle	140° +/-5° (@50% brightness)
Vert. viewing angle	140° +/-5° (@50% brightness)
Brightness uniformity	>98%
Dimming	0-100%
Grey Level	14 bits
Avg Power consumption	400 W/m²	350 W/m²	320 W/m²	300 W/m²	280 W/m²
Max Power consumption	720 W/m²	680 W/m²	640 W/m²	620 W/m²	600 W/m²
Operation power voltage	100-240V / 50-60Hz
Operational temperature	-10°C to +40°C / 14°F to 104°F
Operational humidity	10-80%
IP rating	IP54 for Indoor, IP65 for Outdoor
Dimensions	500 x 500 x 80 mm /500 x 1000 x 80 mm(WxHxD)
Weight	7.25kg(500 x 500mm cabinet)/ 12.5kg (500 x 1000mm cabinet)
Serviceability	Frontal & Rear Service Indoor. Rear Service For Outdoor.
Certifications	CE, UL, FCC class A, RoHS, WEE, REACH
Warranty	3 years standard product warranty
