10kN Three-Wheel Steel Hoisting Tackle with Galvanized Frame for Tower Erection and Lifting Pulley Applications

10kN Three-Wheel Steel Hoisting Tackle For Tower Erection With Galvanized Frame
Overview

The 10kN Three-Wheel Steel Hoisting Tackle is a heavy-duty lifting tool engineered specifically for tower erection and transmission line construction. Featuring a galvanized steel frame and three-sheave design, it provides stable load distribution, smooth operation, and superior lifting efficiency in demanding outdoor environments.


Definition

The 10kN Three-Wheel Steel Hoisting Tackle is a mechanical hoisting block used to lift, position, and tension materials during tower erection operations. With a rated load capacity of 10kN, its three steel sheaves reduce friction, increase mechanical advantage, and ensure safe, controlled lifting performance.


Key Advantages
  • 10kN Rated Load Capacity – Suitable for heavy-duty tower erection and power line construction applications
  • Three-Wheel Design for Higher Efficiency – Distributes load evenly, reduces friction, and enhances lifting stability
  • Galvanized Steel Frame – Provides exceptional corrosion resistance and extended service life in outdoor conditions
  • High Safety & Reliability – Robust steel construction ensures consistent performance under continuous load
  • Low Maintenance & Long Lifespan – Engineered for repeated use in harsh construction environments

Main Features
  • Rated capacity: 10kN
  • Structure: Three-wheel / three-sheave design
  • Material: High-strength steel with galvanized surface treatment
  • Smooth rotation mechanism minimizes rope wear
  • Heavy-duty construction for tower erection applications
  • Compatible with steel wire rope and lifting ropes

Application Areas
  • Transmission and distribution line tower erection
  • Power line construction and maintenance
  • Lifting and positioning of tower components
  • Substation and utility installation projects
  • Industrial hoisting and rigging operations
Technical Specifications
Order NumberModelNumber of SheavesRated Load (kN)Outside Diameter * Width (mm)Weight (kg)Hoisting Point Type
11101QH1GN-1K110Φ100*311.8G | H
11102QH1-2210Φ80*271.8G | H
11103QH1-3310Φ80*272.1G | H
11111QH2-1K120Φ120*352.2G | H | B
11112QH2-2220Φ100*312.6G | H
11113QH2-3320Φ100*313.7G | H
11121QH3-1130Φ150*393.4G | H | B
11122QH3-2230Φ120*354.5G | H
11123QH3-3330Φ100*314.6G | H
11131QH5-1K150Φ166*405.2G | H | B
11133QH5-2250Φ150*395.5G | H
11134QH5-3350Φ120*355.1G | H
11141QH8-1K180Φ205*497.2G | H | B
11142QH8-2280Φ166*408.3G | H
11143QH8-3380Φ150*397.9G | H
11151QH10-1K1100Φ246*6011.4G | B
11152QH10-22100Φ166*4010.2H
11153QH10-33100Φ150*3911.7H
11161QH15-1K1150Φ280*6512.1B
11162QH15-22150Φ205*4912.8H
11163QH15-33150Φ166*4011.8H
11164QH15-44150Φ150*3913.9H

Uses: Applied in line construction for craning weight and similar lifting operations.

Features: Utilizes aluminum alloy side panel and MC nylon sheave for lightweight construction. Monosheave block features open design.

10kN Three-Wheel Steel Hoisting Tackle for tower erection applications
